    ASTM A572 Gr50 Hot Rolling H Shaped Steel Beam

    Ask Lasest Price
    Brand Name : HYX
    Model Number : ASTM A572 Gr50
    Certification : CE
    Price : 399$-699$
    Payment Terms : T/T,L/C
    Supply Ability : 30000Tons/Month
    Delivery Time : 7-15days
    • Product Details
    • Company Profile

    ASTM A572 Gr50 Hot Rolling H Shaped Steel Beam

    H-beam steel is an economical and efficient profile with more optimized section area distribution and more reasonable strength-to-weight ratio, so it is named because its section is the same as the English letter "H". Because all parts of H beam are arranged at right angles, H beam has been widely used for its advantages of strong bending resistance, simple construction, cost saving and light structural weight in all directions.
    Hot Rolled ASTM H Beam W10*22/26/49/60 A572 Gr50 Galvanized Carbon Steel H Section for Bridge Engineering

    Standard Sectional DimensionSectionUnit WeightInformative Reference
    AreaGeometricalRadius ofModulus of
    NominalH X Bt1t2rAmoment of inertiaGyration of areaSection
    Dimensional
    mm
    mmmmmmmmcm2kg/mkg/12m1x cm41ycm4ix cmiy cmZx cm3Zy cm3
    100 x 100100 x100681021.9017.202063831344.182.4776.5026.7
    125 x 125125 x1256.591030.3123.802868472935.293.1113647.00
    150 x150150 x1507101140.1431.503781,6405636.393.75219.0075.10
    175 x175175 x1757.5111251.2140.204822,8809847.504.38330.00112.00
    200 x200200 x2008121363.5349.905994,7201,6008.625.02472.00160.00
    250 x250250 x2509141692.1872.4086910,8003,65010.806.29867.00292.00
    300 x300300 x300101518119.8094.00112820,4006,75013.107.511,360.00450.00
    350 x350350 x350121920173.9137.00164440,30013,60015.208.842,300.00776.00
    Product Name
    High Quality Professional ASTM A572 A36 150X150 Wide Flange Structural Hot Rolled Steel H Beam
    Size
    1.Web Width (H): 100-900mm
    2.Flange Width (B): 100-300mm
    3. Web Thickness (t1): 5-30mm
    4. Flange Thickness (t2): 5-30mm
    Length
    1m - 12m , or according to your requests.
    Standard
    GB ASTM, JIS, SUS, DIN, EN etc
    Material
    Q235B Q345B Q420C Q460C SS400 SS540 S235 S275 S355 A36 A572 G50 G60
    Technique
    Cold Rolled,Hot Rolled or Welded
    Application
    Industry,Construction,Decoration,Shipbuilding,Bridging,etc.
    Price Item
    FOB,CIF,DDU,FCA,EXW ,.etc
    Packing
    Export standard packing or according to customers' requirement
    Supply Ability
    Within 7-10 workdays,25-30days when the quantity beyond 1000tons

    Hot Rolled ASTM H Beam W10*22/26/49/60 A572 Gr50 Galvanized Carbon Steel H Section for Bridge EngineeringMain application of H-beam steel:
    Various civil and industrial building structures; various long-span industrial plants and modern high-rise buildings, especially industrial plants in areas with frequent seismic activities and high-temperature working conditions; large bridges that require large bearing capacity, good section stability, and large spans.

    FAQ:

    Q:What is the brand name of H Shape Steel Beam?
    A:The brand name of H Shape Steel Beam is HYX.
    Q:What is the model number of H Shape Steel Beam?
    A:The model number of H Shape Steel Beam is H126.
    Q:Where is the place of origin of H Shape Steel Beam?
    A:The place of origin of H Shape Steel Beam is Shandong China.
    Q:What kind of certification does H Shape Steel Beam have?
    A:H Shape Steel Beam has CE certification.
    Q:What is the minimum order quantity of H Shape Steel Beam?
    A:The minimum order quantity of H Shape Steel Beam is 1Ton.
