Brand Name : | hyx |
Model Number : | 30 (JIS S30C) |
Certification : | CE ISO CNAS CQC |
Price : | 800$-1500$ |
Payment Terms : | T/T,L/C |
Supply Ability : | 30000Tons/Month |
Delivery Time : | 7-15days |
Steel grade 30 is a high-quality structural steel used when manufacturing parts of low strength, including cylinders, spindles, shafts, couplings, levers and rods.
Classification: High-quality structural carbon steel.
Products: Flat-rolled steel, including shaped.
Chemical composition of steel 30 according to ladle sample in accordance with DSTU 7809 and GOST 1050, %
С | Si | Mn | S | P | Cr |
0.27-0.35 | 0.17-0.37 | 0.5-0.8 | <0.04 | <0.035 | <0.25 |
Minimum yield strength, MPa | Minimum temporary resistance, MPa | Minimum relative elongation, % | Minimum relative reduction, % |
295 | 490 | 21 | 50 |
US | 1030, G10300, M1031 |
Germany | 1.0528, C30, C30E, Ck30 |
Japan | S28C, S30C, S33C, SWRCH30K, SWRCH33K |
France | C30E, FR32, XC32 |
UK | 080M32 |
EU | 1.0528, 1.1178, C30, C30E |
Italy | C30, C30E, C30R |
China | 30, ML25Mn, ML30 |
Bulgaria | 30 |
Poland | 30, 30A, 30rs |
Romania | OLC30 |
Czech Republic | 12031 |
Steel grade 30 has an average level of strength characteristics, which allows it to be used when manufacturing traverses and levers, shafts, sprockets, rods, couplings and other low-loaded parts.
Steel grade 30 has limited weldability. The main welding methods include electroslag welding, automatic arc welding, and manual submerged and shielded arc welding. Heat treatment is recommended when preparing the material.
![]() |
