    S355 S355MLS355N S355NL Hot Rolled Steel Coil EN 10025-4-2004

    Ask Lasest Price
    Brand Name : hyx
    Model Number : S355 S355MLS355N S355NL
    Certification : CE ISO CNAS CQC
    Price : 800$-1500$
    Payment Terms : T/T,L/C
    Supply Ability : 30000Tons/Month
    Delivery Time : 7-15days
    • Product Details
    • Company Profile

    S355 S355MLS355N S355NL Hot Rolled Steel Coil EN 10025-4-2004

    Grade :S355M
    Number:1.8823
    Classification:Alloy special structural steel
    Standard:
    EN 10025-4: 2004 Hot rolled products of structural steels. Technical delivery conditions for thermomechanical rolled weldable fine grain structural steels
    EN 10113-3: 1993 Hot-rolled products in weldable fine grain structural steels. Delivery conditions for thermomechanical rolled steels

    Equivalent grades:Go here

    Chemical composition % of steel S355M (1.8823): EN 10025-4-2004

    Nominal thickness =< 40(mm) CEV max = 0.39
    Nominal thickness from 40 to 63 (mm) CEV max = 0.40
    For long products the P and S content can be 0.005% higher
    For railway application a maximum S content of 0.01% may be agreed at the time of enquiry and order
    In sufficient other N-binding elements are present the minimum total Al content does not applay
    Cu content above 0.45% may cause hot shortness during hot forming
    For long products a maximum C content of 0.18% applies

    S355 S355MLS355N S355NL Hot Rolled Steel Coil EN 10025-4-2004 S355 S355MLS355N S355NL Hot Rolled Steel Coil EN 10025-4-2004


    CSiMnNiPSCrMoVNNbTiAlCuCEV
    max 0.14max 0.5max 1.6max 0.5max 0.03max 0.025max 0.3max 0.1max 0.1max 0.015max 0.05max 0.05max 0.02max 0.55max 0.45

    Mechanical properties of steel S355M (1.8823)

    Nominal thickness (mm):to 4040 - 6363 - 8080 - 100100 - 120
    Rm - Tensile strength (MPa)470-630450-610440-600440-600430-590

    Nominal thickness (mm):to 1616 - 4040 - 6363 - 8080 - 100100 - 120
    ReH - Minimum yield strength (MPa)355345335325325320

    KV - Impact energy (J) longitud.,+20°
    55

    47
    -10°
    43
    -20°
    40

    KV - Impact energy (J) transverse,+20°
    31

    27
    -10°
    24
    -20°
    20

    A - Min. elongation Lo = 5,65 √ So (%)22

    Equivalent grades of steel S355M (1.8823)

    Warning! Only for reference

    EU
    EN
    USA
    -
    Germany
    DIN,WNr
    France
    AFNOR
    England
    BS
    European old
    EN
    Italy
    UNI
    Sweden
    SS
    S355M
    A572Gr.C
    A913Gr.50

    StE355
    StE355TM

    E355
    E355R

    50D

    FeE355KGTM

    FeE355KG
    FeE355KGTM

    2134-01
