Brand Name : | hyx |
Model Number : | S275JR S275J0 S275J2 S275N S275NL |
Certification : | CE ISO CNAS CQC |
Price : | 800$-1500$ |
Payment Terms : | T/T,L/C |
Supply Ability : | 30000Tons/Month |
Delivery Time : | 7-15days |
Steel grade S275JR is a structural steel that meets the requirements of the EN 10025-2 standard.
Classification: Non-alloy structural steel.
Products: Flat and long hot-rolled products and semi-finished products.
C for nominal thickness in mm | Mn | P | S | N | Cu | ||
≤ 16 | ˃16 ≤ 40 | ˃ 40 | |||||
≤ 0.21 | ≤ 0.21 | ≤ 0.22 | ≤ 1.50 | ≤ 0.035 | ≤ 0.035 | ≤ 0.012 | ≤ 0.55 |
Nominal thickness, mm | Minimum yield strength, MPa | Strength limit, MPa |
<3 | 275 | 430-580 |
≥3 ≤ 16 | 275 | 410-560 |
> 16 ≤ 40 | 265 | 410-560 |
> 40 ≤ 63 | 255 | 410-560 |
> 63 ≤ 80 | 245 | 410-560 |
> 80 ≤ 100 | 235 | 410-560 |
> 100 ≤ 150 | 225 | 400-540 |
> 150 ≤ 200 | 215 | 380-540 |
> 200 ≤ 250 | 205 | 380-540 |
> 250 ≤ 400 | 195 | 380-540 |
Germany | St44-2 |
France | E28-2 |
UK | 43B |
Europe (outdated) | Fe430B |
Sweden | 1412-00 |
Norway | NS12142 |
Steel grade S275JR is used in the form of long and flat products to manufacture welded and riveted steel structures, and can also be used in the machine building industry for low-load parts, including bushings, shafts and axles.
Steel grade S275JR can be welded without restrictions, welding occurs without preheating and without subsequent heat treatment.
![]() |
