Chain link fence is also known as diamond wire mesh fence, it is woven with high
quality mild steel wire/low carbon steel wire/galvanized iron wire.
It has the features of woven simple, beauty and practical. It's
finish treatment is galvanized and plastic coated with long- time
use and corrosion protection. They are widely used as protective
fence in residential sites, roads and sports fields.
Materials: High quality mild steel wire, galvanized iron wire, pvc coated iron
wire, galfan steel wire, stainless steel wire, aluminum alloy wire,
Features: smooth surface, durable, knit simple and elegant appearance. And
the products are easy to transport and install. PVC chain link
fences have different colors with decorative and antiseptic
features in harmony with environment. They are popular protective
fence at home and abroad.
Fence Type: Galvanized chain link fence, PVC coated chain link fence, stainless
steel chain link fence.
Treatment: Electro galvanized, hot-dipped galvanized.pvc coated
application: fence for field, for zoo fence, for protection of highway,
residential sites, and for slope protection net, for coal inside
roof support fence, etc
| 1" | 1.5" | 2" | 2-1/4" | 2-3/8" | 2-1/2" | 2-5/8" | 3" | 4" |
| 25 | 40 | 50 | 57 | 60 | 64 | 67 | 75 | 100 |
| Wire diameter | 18#-13# | 16#-18# | 18#-7# |
| 1.2-2.4mm | 1.6-4.2mm | 2.0-5.0mm |
| Length/roll | 0.50m-5.0m (can be longer) |
| Width | 0.5m-5.0m |
| Materials and specifications can be made as request. |
hot dip galvanized chain link fence
It is available with:• Galvanized or PVC coated - standard mesh or
micromesh.• Barbed wire and razor wire for added security
protection.• Anti-climb and anti-cut features for higher
security.•Suitable for many occasions,like backyard, children's
playgrounds, sport fields, recreational grounds.
| Material | Galvanized steel wire |
| Height | 0.5m-6m |
| Length | 4m-50m |
| Mesh Opening | 20*20mm,50*50mm, 60*60mm,80*80mm etc |
| Wire diameter | 1.0mm-6.0mm |
| Technique | Woven |
| Post & rail diameter | 32mm, 42mm, 50mm, 60mm, 76mm, 89mm etc |
| Post & rail thickness | 1.5mm, 2.0mm, 3.0mm, 4.0mm, 5.0mm etc |
| Post type | Round post, angle post, square post, etc |
| Edge type | Knuckle type, twist type, special type |
| Surface treatment | Electric galvanized, hot dipped galvanized, PVC coated |
